EcoPure EP40 - Manual (Page 27)

27
Valve Parts List
Key
No.
Part No. Description
50 7338111 Screw, #6-19 x 3.5 cm (2 req.)
51 7281291 Motor
52 7337474 Motor Mount
53 7284964 Cam & Gear
54 7030713 Switch
– 7331185
Drain Hose Adaptor Kit
(includes Key Nos. 55-59)
55 á Clip, Drain
56 á Drain Hose Adaptor
57 á Hose Clamp
58 á O-Ring, 15.9 x 20.6 mm
59 á Flow Plug, 7.6 lpm
– 7129716 Seal Kit (includes Key Nos. 60-65)
60 á O-Ring, 11.1 x 15.9 mm
61 á O-Ring, 19.1 x 23.8 mm
62 á O-Ring, 85.7 x 92.1 mm
63 á Rotor Seal
64 á O-Ring, 9.5 x 14.3 mm
65 á Seal, Nozzle & Venturi
66 7082087 Wave Washer
67 7199232 Rotor & Disc
68 7092642 Plug, Drain Seal
69 7129889 Spring
70 7337563 Clip, 3/4”, pack of 4
71 7278442
Installation Adaptor, 3/4” (2 req.),
including O-Ring (See Key No. 72)
72 7337571 O-Ring, 23.8 x 30.2 mm, pack of 4
– 7113040
Turbine & Support Assembly,
including 2 O-Rings (See Key No.
72) & 1 ea. of Key Nos. 73 & 74
73 á Turbine Support & Shaft
74 á Turbine
Key
No.
Part No. Description
75 7082053 Valve Body
76 7081201 Retainer, Nozzle & Venturi
77 7170319 O-Ring, 6.4 x 9.5 mm (2 req.)
78 1202600 Nut - Ferrule
–
7187065
Nozzle & Venturi Assembly,
Models EP27, EP30 & EP34
(includes Key Nos. 79-87)
7253808
Nozzle & Venturi Assembly,
Model EP40 (incl. Key Nos. 79-87)
79 7081104 Housing, Nozzle & Venturi
80 7095030 Cone Screen
81 1148800 Flow Plug, 1.1 lpm
82
7187772
Nozzle & Venturi Gasket Kit,
Models EP27, EP30 & EP34
7114533
Nozzle & Venturi Gasket Kit,
Model EP40
7204362 Gasket Only
83
0521829
Flow Plug, 0.37 lpm,
Models EP27, EP30 & EP34
7084607 Flow Plug, 0.57 lpm, Model EP40
84 7146043 Screen
85 7167659 Screen Support
86 7170262 O-Ring, 28.6 x 34.9 mm
87 7199729 Cap
88 7309803 Wire Harness, Sensor
89 7337466 Valve Cover
90 7074123 Screw, #10-14 x 5 cm (5 req.)
91 7278434
Bypass Valve Assembly, 3/4”, in -
cluding 2 O-Rings (See Key No. 72)
