Belt grinder SM-140 14
Structure and Function
6
6.2 Structure
Figure 6.1 – Structure of the belt grinder
[1] Grinding arm
[2] Sprayhood
[3] Direction of rotation of the grinding belt
[4] Grinding belt
[5] Water tank
[6] Switch
[7] Machine base
[8] Polishing station
[9] Polishing wheel
[10] Direction of rotation of the polishing wheel
1
2
3
4
5 6
7
8
9
10
