Belt grinder SM-140
13
Structure and Function
6
6. Structure and Function
6.1
Technical data
Motor and electrics
Grinding belt
Polishing wheel
Machine dimensions / weights
Emissions sound pressure level
Sound emissions to EN ISO 11201 during the grinding of boning knives.
Power:
0.25 kW
Voltage: 1~230
V
Current intensity:
1.7 A
Frequency:
50 Hz (60 Hz)
Degree of protection: IP 54
Type of operation:
S2 - 60 min
Connection:
1.8 m cable H05VV-F3G1.0
CEE 7/7 Euro earthing pin plug
Nominal speed:
1400 rpm (50 Hz)
Dimensions:
1000 x 50 mm
Cutting speed:
V
c
= 14.3 m/s (50 Hz)
Dimensions:
200 x 25 x 16 mm
Cutting speed:
V
c
= Vc = 14.3 m/s (50 Hz)
with polishing wheel diameter 200 mm
Depth: 446 mm
Width:
563 mm
Height:
416 mm
Weight:
19.5 kg
Emission sound pressure level in idle state L
pA
: 73 dB (A)
Uncertainty K
pA
:
3 dB (A)
Emissions sound pressure level L
pA
:
77 dB (A)
Uncertainty K
pA
:
3 dB (A)
