Advanced Phone Features
111
the local network then listens to the RTP on the preconfigured multicast address (IP:
Port). For both sending and receiving of the multicast RTP, there is no SIP signaling
involved.
The multicast paging key LED illuminates solid green.
The following figure shows a multicast RTP session on the phone:
2. Press the Hold soft key to place the current multicast RTP session on hold.
3. Press the Cancel soft key to cancel the multicast RTP session.
Note
You can configure the phone to receive a Real Time Transport Protocol (RTP) stream from
the pre-configured multicast address(es) without involving SIP signaling. You can
specify up to 10 multicast addresses that the phone listens to on the network.
How the phone handles incoming multicast paging calls depends on Paging Barge and
Paging Priority Active parameters configured via web user interface.
Paging Barge
Paging barge parameter defines the priority of the voice call in progress. If the priority
of an incoming multicast paging call is lower than that of the active call, it will be
ignored automatically. If Disabled is selected from the pull-down list of Paging Barge,
the voice call in progress takes precedence over all incoming multicast paging calls.
Valid values in the Paging Barge field:

1 to 10: Define the priority of an active call, 1 is the highest priority, 10 is the lowest.

Disabled: The voice call in progress shall take precedence over all incoming
paging calls.
Paging Priority Active
Paging priority active parameter decides how the phone handles the incoming
multicast paging calls when there is already a multicast paging call on the phone. If
enabled, the phone will ignore incoming multicast paging calls with lower priorities,
otherwise, the phone will answer incoming multicast paging calls automatically and
Multicast RTP is one way only- from sender to the multicast address(es) (receiver). For
outgoing RTP multicasts, all other existing calls on the phone will be placed on hold.
