6
3 Start Up
Warning – You must connect antenna(s) to the SMA style antenna connectors on the router before turning it on.
Failure to do this could result in erratic start up behavior and could possibly damage the unit.
Note – Z Series routers ship from the factory with DHCP server enabled. The Default Gateway address for the
unit is 192.168.1.10. The address of the web based administration is also 192.168.1.10. After you have activated
your unit on the wireless network it WILL NOT have a DNS address, meaning that public Internet web access will
not work. To load DNS values go to the Ethernet Interface screen, select “Acquire From Wireless Network” and
press the update button. At this point the Primary and Secondary DNS addresses in the Ethernet Interface screen
will be populated with the DNS addresses provided by your wireless network. As a last step restart both the
router and the connected PC.
3.1 Power
Before starting connect the supplied 12VDC power adapter to the power connector described in Section 2. The adapter
supplied with your router is suitable for use with 120VAC 60-hertz wall power. If you need a different power solutions
contact Ctek.
3.2 Connecting the Antenna
Antennas should be attached to the SMA style antenna connectors described in section 3. The antenna must be
connected before powering the unit on. ON the Z4200 the antenna connector to the right of the LAN LED is the primary
(transmit/receive) antenna and the connector to the left of the reset button is the secondary or diversity antenna.
3.3 Connecting to the Ethernet Port – Administrative Connection
For a direct Ethernet connection between a PC connect to the Ethernet port using a standard or reverse Ethernet cable.
For initial configuration and administration with a PC or workstation Ctek recommends that the PC be set to obtain an IP
address and obtain a DNS address automatically. For Windows PCs make the following settings under the networking
control panel
