Step 4 Install the Camera

Initial Setting and

Insta

llatio

of Camer

Note

Observe the following items when connecting the interface cables.

• Firmly insert the dedicated terminals on the audio interface cable into the

audio input/output terminals on the camera.

• Affix each interface cable in the specified groove, as shown below.

If the cable is not properly installed, it may come off and cause the camera to

malfunction.

Power

Audio

I/O

Affixing groove for cable

Interface cable fixing method
