Bio-Rad Criterion™ XT Tris-Acetate Precast Gels - Manual (Page 7)

1.3 Criterion System Specifications
Gel material Polyacrylamide
Gel dimensions (W x L) 13.3 x 8.7 cm
Gel thickness 1.0 mm
Resolving gel height 6.5 cm
Cassette dimensions (W x L) 15.0 x 10.6 cm
Cassette material Styrene copolymer
Comb material Polycarbonate
Storage tray material PET
Upper running buffer volume 60 ml
Lower running buffer volume 800 ml
Storage conditions Bis-Tris gels: Store flat at ambient temperature; DO NOT FREEZE
Tris-acetate gels: Store flat at 4°C; DO NOT FREEZE
Gel shelf life 12 months for Bis-Tris gels; 8 months for Tris-acetate gels
1.4 Criterion XT Comb Configurations
Comb Load Volume Comments
12+2 well 45 µl with two 15 µl reference wells Multichannel pipet compatible
18-well 30 µl
26-well 15 µl Multichannel pipet compatible
Prep+2 well 800 µl with two 15 µl reference wells
IPG 11 cm ReadyStrip  IPG strip
IPG+1 well 11 cm ReadyStrip IPG strip with one 15 µl reference well
