3 - 2
OUTDRIVE DRIVE UNIT
DESCRIPTION
A compact reversible 12V DC hydraulic pump/reservoir unit with
actuating cylinder for autopilot control of outdrive power-assisted
hydraulic steering systems. Mounting brackets for attaching the cylinder
to the power steer unit depends upon engine type and are listed below.
Other brackets available on request. Mechanical installation instructions
are supplied with the brackets.
OUTDRIVE DRIVE UNIT DATA
MOUNTING BRACKET KITS
VOLVO
STANDARD 345-30-280
VOLVO AQ. D40 345-30-281
MERCRUISER
345-30-282
OMC 345-30-283
YAMAHA 345-30-284
PUMP
TYPE
Reversible DC
motor
SUPPLY 12V DC
WEIGHT 2.7kg
