Introduction | ZM Series User Manual
Introduction
The B&G ZM Series monitors offer a low profile, high brightness solution for displaying video
from a variety of sources. This includes two models; the ZM16”, and ZM19” Touch monitors.
These models are suited for both indoor and outdoor use. Both monitors accept video via
HDMI, DVI-I and composite inputs.
Items included
1
2
18
12
13
17
16
10
19 20
3
4
5
9
8
6
7
11
15
14
1 Monitor
2 Dash mount brackets (x2)
3 Washer, M4, 12mm, SS (x4)
4 Pozi pan head machine screw, M4 x 12mm, SS (x4)
5 Plastic spacer (x4)
6 Wing nut M5 (x4)
7 Wing head machine screw (x4)
8 Plastic stopper - dash mount (x4)
9 Pozi pan head self-tapping screw 4G x 1/2” (x12)
10 Cable retention bracket with screws 4G x 1/2” (x4)
11 Cable ties (x4)
12 Connector block (serial data)
13 Micro-C tee piece
14 Micro-C cable, 2m (6ft)
15 Power cable with connector
16 Bezel trim, black (x2)
17 Bezel trim, silver (x2)
18 Operator manual
19 Cutout template
20 Warranty card
