18 |
General specifications | ZM Series User Manual
General specifications
LCD display
15.6” TFT Active Matrix
Panel
18.5” TFT Active Matrix
Panel
Weight (monitor only):
ZM16T = 3.60Kg
ZM19T = 4.60Kg
Brightness
1000nit
Screen glass
AF, AR
Native resolution
ZM16: 1366x768
ZM19: 1366x768
Protection
Thermal: auto screen
dimming, overvoltage,
reverse polarity, low
voltage
Contrast
ZM16: 500:1
ZM19: 1000:1
Power and setup keys Capacitive touch
View angle
60/60 Horizontal 60/60
Vertical
Comms / Control RS422, USB, NMEA 2000
Display colours 16.7 million Video inputs
1x HDMI, 1x DVI-I, 2x
composite (NTSC & PAL)
Operating temp
-15 to +55 degrees
Celsius
Picture in Picture
YES; variable position
& size
Non operating temp
-20 to 60 degrees
Celsius
Auto video detection YES
Operable humidity 95% Auto video scaling YES
Water ingress resistance
IPX2 (bracket mount)
IPX5 (dash mount - front
only exposed)
Supply voltage 12V / 24V DC (9-31.2V)
Bezel & rear case PC/ABS Power consumption
20W, 25W
Supported Resolutions
640 x 480
(8-32 bit colour, 59, 60 Hz)
720 x 480
(8-32 bit colour, 59, 60 Hz)
720 x 576
(16-32 bit colour, 50-60 Hz) 800 x 480
(8-32 bit colour, 60 Hz)
800 x 600
(8-32 bit colour, 60 Hz)
1024 x 600
(8-32 bit colour, 60 Hz)
1024 x 768
(8-32 bit colour, 60 Hz) 1280 x 768
(8-32 bit colour, 60 Hz)
1280 x 720
(8-32 bit colour, 50-60 Hz)
1360 x 768
(8-32 bit colour, 60 Hz) 1366 x 768
(8-32 bit colour, 60 Hz)
1920 x 1080
(8-32 bit colour, 50-60 Hz)
1920 x 1080
(8-32 bit colour, 25, 29, 30
Hz Interlaced)
¼ Note: Occasionally specifications may change - refer to the latest edition of the manual on the
website: www.bandg.com
