Appendix f, Wiring diagram 2 in 1 display module, 2 in 1 module sensor module – Amico Nema 4 Master Alarm User Manual
Page 43
www.amico.com
43
Black
Red
# 22 Gauge twisted
pair shielded cable
6”-8” [0.1m-0.2m] supplied
2 in 1
Module
Sensor
Module
C
NC
C
NC
C
NC
C
NC
C
NC
1
H
C
2
H
C
3
H
C
4
H
C
5
H
C
+
+
+
+
+
-
-
-
-
-
NO NC COM NO NC COM
- +
Note:
Jumper any
unused points
Source Equipment
Dry contacts for
remote monitoring of
High and Low alarms
Dry contacts
only, no
voltage
OXYGEN
Appendix F
Wiring Diagram
2 in 1 Display Module
