Raven SCS 450 Setup Data:
BOOM CAL SPEED METER VALVE
Model Description 1 (LH) 2 (CTR) 3 (RH) CAL CAL CAL
NP4000-1630 40-Foot, 16-Row 480 inches Cable Body
w/o Section Control 30-Inch (1219.2 cm)
NP4000-1630 40-Foot, 16-Row 180 inches 120 inches 180 inches Cable Body
w/Section Control 30-Inch (457.2 cm) (304.8 cm) (457.2 cm)
NP4000-1630+SD 40-Foot, 17-Row 510 inches Cable Body
w/o Section Control 30-Inch, Side Dress (1295.4 cm)
NP4000-1630+SD 40-Foot, 17-Row 210 inches 120 inches 180 inches Cable Body
w/Section Control 30-Inch, Side Dress (533.4 cm) (304.8 cm) (457.2 cm)
NP4000A-16C30 40-Foot, 16-Row 480 inches Cable Body
w/o Section Control 30-Inch (1219.2 cm)
NP4000A-16C30 40-Foot, 16-Row 180 inches 120 inches 180 inches Cable Body
w/Section Control 30-Inch (457.2 cm) (304.8 cm) (457.2 cm)
NP4000A-16C30+SD 40-Foot, 17-Row 510 inches Cable Body
w/o Section Control 30-Inch, Side Dress (1295.4 cm)
NP4000A-16C30+SD 40-Foot, 17-Row 210 inches 120 inches 180 inches Cable Body
w/Section Control 30-Inch, Side Dress (533.4 cm) (304.8 cm) (457.2 cm)
NP4000B-1238 40-Foot, 12-Row 456 inches Cable Body
w/o Section Control 38-Inch (1158.2 cm)
NP4000B-1238 40-Foot, 12-Row 152 inches 152 inches 152 inches Cable Body
w/Section Control 38-Inch (386.1 cm) (386.1 cm) (386.1 cm)
NP4000B-1240 40-Foot, 12-Row 480 inches Cable Body
w/o Section Control 40-Inch (1219.2 cm)
NP4000B-1240 40-Foot, 12-Row 160 inches 160 inches 160 inches Cable Body
w/Section Control 40-Inch (406.4 cm) (406.4 cm) (406.4 cm)
1. Suggested initial value. Refine using calibration procedure in Raven SCS 450 manual.
2. This value is printed on a durable tag attached to the meter cable.
3. This value, for example “2123”, is printed on the label on the valve body.
