Chain Routing (Option)
See also “Chain Maintenance (Option)” on page 138.
Ground Drive Chain
Legend:
Sprocket or idler Tooth count
Chain Pitch count
Direction of chain in motion
34T
56P
15T
25T
122P
U
D
F
B
L
R
31079
99P
47T
15T
15T
