Carrier IDEALCOMFORT 58MVC - Manual (Page 7)

7
A07563
Fig. 10 -- Furnace Pressure and Drain Tubing Diagram
;; ;;
BURNER FLAME
BURNER
MANIFOLD
A89020
Fig. 11 -- Burner Flame
NOTE: Use propane gas resistant pipe dope to prevent gas leaks.
DO NOT use Teflon tape.
FIRE, EXPLOSION, UNIT DAMAGE HAZARD
Failure to follow this warning could result in personal
injury, death, or property damage,.
Gas valve switch MUST be facing forward or tilted slightly.
!
WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow this warning could result in personal
injury or death or property damage.
Never test for gas leaks with an open flame. Use a
commercially available soap solution made specifically for
the detection of leaks to check all connections.
!
WARNING
58MV
C
