Great Plains Manufacturing, Inc. Adjustments 41
2013-05-10 118-231M
Meter Exchange (25 Series only)
1.
Empty seed box.
Note: The sliding gate at gravity-fed seed meters only
shuts off seed flow if a meter is present.
2. Clean out meter. See “Cleaning Out Meters” on
page 63.
Refer to Figure 54
3. Loosen the screw clamp securing the grommet to
the inner sliding seed tube.
Refer to Figure 55
4.
Release the upper latch.
5. Swing the drive mount away from the meter.
Refer to Figure 56
6.
Release the lower latch.
Refer to Figure 57
7.
Slide inner seed tube up and out of meter grommet
(not shown).
8. Lift meter body up, then back, and remove the
meter. Catch the seed tube so that it doesn’t fall to
the ground.
9. Remove the screw clamp from the grommet.
Figure 54
Seed Hose Retaining Clamp
22853
1
Figure 55
Upper Meter Latch
22865
1
Figure 56
Lower Meter Latch
22866
Figure 57
Meter Removal
22867
