2013- Single Fold Marker
Great Plains Mfg., Inc.
113-850M
2013-10-10
Null4:
55
1
SFM-8657
SFM-8657
Subframe Left - SFM
HAUKAAS SUBFRAME LEFT SFM
56
1
SFM-8658
SFM-8658
Subframe Right SFM
HAUKAAS SUBFRAME RIGHT SFM
57
1
SFM-8659
SFM-8659
End Bushing Right SFM
HAUKAAS END BUSHING RIGHT SFM
58
1
SFM-8660
SFM-8660
End Bushing Left SFM
HAUKAAS END BUSHING LEFT SFM
59
1
SFM-8661
SFM-8661
Pivot Frame Left SFM
HAUKAAS PIVOT FRAME LEFT SFM
60
1
SFM-8662
SFM-8662
Pivot Frame Right SFM
HAUKAAS PIVOT FRAME RIGHT SFM
61
2
SFM-8663
SFM-8663
Primary Arm SFM
HAUKAAS PRIMARY ARM SFM
62
2
SFM-8664
SFM-8664
Second Stage Arm SFM
HAUKAAS SECOND STAGE ARM SFM
63
2
SFM-8665
SFM-8665
Third Stage Arm SFM
HAUKAAS THIRD STAGE ARM SFM
64
2
SFM-8666
SFM-8666
Spring Holder SFM
HAUKAAS SPRING HOLDER SFM
65
2
SFM-8667
SFM-8667
Arm Rest SFM
HAUKAAS ARM REST SFM
66
2
SFM-8668
SFM-8668
Cylinder Pin SFM
HAUKAAS CYLINDER PIN SFM
67
1
SFM-8669
SFM-8669
Mounting Bracket Right SFM
HAUKAAS MOUNTING BRACKET RIGHT
68
1
SFM-8670
SFM-8670
Mounting Bracket Left SFM
HAUKAAS MOUNTING BRACKET LEFT
69
2
SPR-2395
SPR-2395
DSA/MED/CB Spring 02-200934-1
HAUKAAS MEDIUM CB SPRING
a Some of this count is found in subordinate kits.
Figure 21
Callout
Quantity
in Kit
Haukaas Part No.
GP Part Number
Haukass Part Description
Great Plains Part Description
