Operating Instructions 25
08/03/2010 160-269M-A
Refer to Figure 26
9.
Remove the wing lock pin from its storage location
just outboard of the wing hinge point.
Refer to Figure 27
10. Install wing lock pins under hinge points to secure
folded wings for transport or parking.
Figure 26
Wing Lock Pin Stored
17155
1
Figure 27
Wing Locked Up With Pin
17171
2
