WHEATHEART - GHR & WHR GRAIN AUGERS
3. A
SSEMBLY
PTO-SD D
RIVE
M
ODEL
3.9. D
ISCHARGE
S
POUT
30641 R1
27
Figure 3.10
3.9. DISCHARGE SPOUT
1. Attach discharge spout with half tube clamps and 7/16” x 1-3/4” bolts and
locknuts as required. Note that some augers are equipped with weld-on
discharge spouts.
Note:
If a safety spout is being used with this auger, the safety release door should be
on the left side of the auger, as determined when standing at intake, facing the
discharge end.
Table 3.5 Driveshaft Shielding Sequence
Auger Size/
Length
Step 1
Step 2
Step 3
Step 4
Step 5
Qty
Length
Qty
Length
Qty
Length
Qty
Length
Qty
Length
8” x 31’
1
42”
(1.07 m)
1
48”
(1.22 m)
1
42”
(1.07 m)
3
48”
(1.22 m)
1
42"
(1.07 m)
8” x 36’
1
42”
(1.07 m)
1
48”
(1.22 m)
1
42”
(1.07 m)
4
48”
(1.22 m)
1
42"
(1.07 m)
8” x 41’
3
42”
(1.07 m)
1
48”
(1.22 m)
1
42”
(1.07 m)
4
48”
(1.22 m)
1
42"
(1.07 m)
8" x 46’
5
42”
(1.07 m)
4
60”
(1.52 m)
1
48”
(1.22 m)
--
--
--
--
8" x 51’
2
42”
(1.07 m)
1
48”
(1.22 m)
6
60”
(1.52 m)
1
48”
(1.22 m)
--
--
8" x 56’
2
42”
(1.07 m)
11
48”
(1.22 m)
1
42”
(1.07 m)
--
--
--
--
8" x 61’
1
48”
(1.22 m)
2
42”
(1.07 m)
11
48”
(1.22 m)
1
42”
(1.07 m)
--
--
8" x 71’
4
42”
(1.07 m)
1
48”
(1.22 m)
1
42”
(1.07 m)
11
48”
(1.22 m)
1
42"
(1.07 m)
10" x 31’
1
42”
(1.07 m)
5
48”
(1.22 m)
1
42”
(1.07 m)
--
--
--
--
10" x 41’
1
48”
(1.22 m)
3
42”
(1.07 m)
5
48”
(1.22 m)
1
42”
(1.07 m)
--
--
10" x 51’
11
48”
(1.22 m)
1
42”
(1.07 m)
--
--
--
--
--
--
10" x 61’
1
48”
(1.22 m)
2
42”
(1.07 m)
11
48”
(1.22 m)
1
42”
(1.07 m)
--
--
10" x 71’
4
42”
(1.07 m)
1
48”
(1.22 m)
1
42”
(1.07 m)
11
48”
(1.22 m)
1
42"
(1.07 m)
