LaMotte SMART 3 Electronic Soil Lab - Manual (Page 47)

SMART3 Soil 1.11 47
BATTERY
BATTERY/AC OPERATION 
The SMART3 may be operated on battery power or using a USB wall adapter or
USB computer connection. If using the meter as a bench top unit, use the wall
adapter if possible to extend the battery life. The meter will remain on when the
USB adapter is used.
To charge the battery with the wall adapter, plug the smaller end of the USB
cable (USB mini B connector) into the meter and the larger end of the USB
cable (USB Type A connector) into the wall adapter. Plug the wall adapter into
an AC outlet. Reinsert the USB port plug after charging.
To charge the battery from a computer, plug the smaller end of the USB cable
(USB mini B connector) into the meter and the larger end of the USB cable (USB
Type A connector) into a USB port on a computer. Reinsert the USB port plug
after charging.
The battery icon will show no bars and flash when the unit first turns on. Then
the indicator will indicate the battery status by showing 0, 1, 2, 3 or 4 bars.
It will take 5 hours to fully charge a low battery. The battery icon will flash when
the battery is charging. The battery icon will show four bars and stop flashing
when it is fully charged. The charging circuit will automatically switch to a float
charge when the battery is fully charged. The charger may remain connected.
Some computers will NOT supply power to their USB ports during standby
operation. The wall adapter will charge the unit continuously.
The battery icon will show no bars and continuously flash if the battery is getting
low but the unit will still operate normally. A “Low Battery” message on the
status bar of the display will replace the time when the battery voltage is too
low for proper operation and accuracy may be degraded. A “Shutdown Low
Batt” message on the display will appear for a few seconds before the power is
switched off when the battery is too low to operate the unit.
To extend the battery life:
Shut down the unit with the power switch when not taking measurements •
or use the power save option to have the unit automatically turn off after 5
minutes.
Store the unit in a cool dry place.
•
Fully charge the battery before storing the unit for extended periods of time. •
Limit backlight use. The unit consumes 3X normal power with the backlight •
on. Set the backlight time option to 10 seconds, or select “Button Control”
and keep the backlight off.
BATTERY REPLACEMENT 
The lithium ion battery used in this unit should last for many years with
normal use. When it no longer powers the unit long enough to meet testing
