2
FIGURE 5 - BIRd SCREEn InSTallaTIon
FIGURE 6 - SnaP InTo PlaCE
1.4 Storm hood is ready for installation
(See FIGURE 7).
FIGURE 7 - ComPlETE aSSEmBly
Bird Screen
Screen Clips
2.0 Storm hood aSSembly and partS liSt
1
2
3
4
5
6
9
7
8
table 1 - partS liSt
item description Qty
1 Top Panel 1
2 left Side Panel 1
3 Right Side Panel 1
4 Bottom Panel 1
5 Bird Screen 1
6
Bolt 1/4”-20 UnC x 3/4”lG,
hEx head
8
7 lock Washer 1/4” Split 8
8 Washer 1/4” S.a.E. 16
9
nut 1/4”-20 UnC
hexagonal
8
