SECTION TSM 445
PAgE
11 Of 11
ISSUE C
VIKING PUMP, INC. • A Unit of IDEX Corporation •
Cedar Falls, IA 50613 USA
© 3/2013 Viking Pump Inc.
All rights reserved
TECHNICAL SERVICE MANUAL
WARRANTY
Viking warrants all products manufactured by it to be
free from defects in workmanship or material for a
period of one (1) year from date of startup, provided
that in no event shall this warranty extend more than
eighteen (18) months from the date of shipment from
Viking. The warranty period for Universal Seal series
pumps ONLY (Universal Seal models listed below) is
three (3) years from date of startup, provided that in
no event shall this warranty extend more than forty-two
(42) months from the date of shipment from Viking.
UNDER NO CIRCUMSTANCES SHALL VIKING BE
LIABLE UNDER THIS WARRANTY OR OTHERWISE
FOR SPECIAL, INCIDENTAL, INDIRECT,
CONSEQUENTIAL OR PUNITIVE DAMAGES OF ANY
KIND, INCLUDING, BUT NOT LIMITED TO, LOST
OR UNREALIZED SALES, REVENUES, PROFITS,
INCOME, COST SAVINGS OR BUSINESS, LOST OR
UNREALIZED CONTRACTS, LOSS OF GOODWILL,
DAMAGE TO REPUTATION, LOSS OF PROPERTY,
LOSS OF INFORMATION OR DATA, LOSS OF
PRODUCTION, DOWNTIME, OR INCREASED
COSTS, IN CONNECTION WITH ANY PRODUCT,
EVEN IF VIKING HAS BEEN ADVISED OR PLACED
ON NOTICE OF THE POSSIBILITY OF SUCH
DAMAGES AND NOTWITHSTANDING THE FAILURE
OF ANY ESSENTIAL PURPOSE OF ANY PRODUCT.
THIS WARRANTY IS AND SHALL BE VIKING’S SOLE
AND EXCLUSIVE WARRANTY AND SHALL BE IN
LIEU OF ALL OTHER WARRANTIES, EXPRESS
OR IMPLIED, INCLUDING, BUT NOT LIMITED
TO, ALL WARRANTIES OF MERCHANTABILITY,
FITNESS FOR A PARTICULAR PURPOSE AND
NON-INFRINGEMENT ALL OF WHICH OTHER
WARRANTIES ARE EXPRESSLY EXCLUDED.
See complete warranty at www.vikingpump.com.
PRESSURE ADJUSTMENT
IMPORTANT
DANgER !
Before starting pump, be sure all drive
equipment guards are in place.
failure to properly mount guards may
result in serious injury or death.
ASSEMBLY
Reverse the procedures outlined under “Disassembly,”
page 10. If the valve is removed for repairs, be sure to
replace in the same position. The relief valve adjusting screw
cap must always point towards the suction side of the pump.
If pump rotation is reversed, remove the relief valve and turn
end for end.
If a new spring is installed or if pressure setting of the
pressure relief valve is to be changed from that which the
factory has set, the following instructions must be carefully
followed.
1. Carefully remove the valve cap that covers the adjusting
screw.
2. Loosen the locknut that locks the adjusting screw so
the pressure setting will not change during operation of
the pump.
3. Install a pressure gauge in the discharge line for the
actual adjusting operation.
4. Turn the adjusting screw in to increase the pressure and
out to decrease the pressure.
5. To test the valve setting, slowly close the line valve on
the downstream side of the pump until the pressure
relief valve opens and flow through the pump stops. This
will show the maximum discharge pressure the valve
allows at the current setting. Limit the amount of time
in this condition to prevent overheating of the pump due
to internal recirculation of the liquid.
In ordering parts for the pressure relief valve, always
give the model number and serial number of the pump
as it appears on the nameplate and the name of the part
wanted. When ordering springs, be sure to give the pressure
setting desired.
LVP SERIES VANE PUMPS
SERIES LVP STAINLESS STEEL
SIZES 01, 02, 05, 08, 19 AND 23
