Page 25
7.4 Tool List
Listed below are tools required for the maintenance of the Acculobe pump.
Type Size or Range
Rotor Retainer Tool Supplied
Seal Removal Tool Supplied
Hexagon (Allen) Keys 4 mm, 5 mm, 6 mm
Depth Micrometer 0 - 25 mm
Feeler Gauge Set -
Rolling Torque Meter 0 – 25 NM (18.5 ft lbs)
Torque Wench 0 - 65 NM (48 ft lbs)
7.5 Pump Data
Pump Weight with Foot Mount: 9.75 kg (21.5 lbs)
Pump Weight for Drop in Style TBA kg (XXX lbs)
Pump Weight with IEC Motor Adaptor: TBA kg (XXX lbs)
Pump Weight with Nema Motor Adapter: TBA kg (XXX lbs)
