Tweco 4-3054 User Manual
Page 6
Manual 0-4964 Rev AA.01
February 5, 2007
6
SW13: TVA and XTL Switch positions
Art # A-07671
SW11
SW13
SW6
SW12
SW13
1
2
1
2
TVA
XTL-TVA
9. This ends the installation instructions for the XTL Torch Valve Assembly Kit.
NOTE
Operation of the Torch Valve is controlled by the Gas Control Module. The Torch Valve does not require
any adjustment or calibration.
NOTE
Every effort has been made to provide complete and accurate information in this manual. However,
the publisher does not assume and hereby disclaims any liability to any party for any loss or damage
caused by errors or omissions in this Manual, whether such errors result from negligence, accident, or
any other cause.
