Anti-spAtter mist ApplicAtor
2-4 SM-QRM-100 intRoduction And deScRiption
2.03 Introduction
Tweco ® Robotics QRM-100 Anti-Spatter Mist Applicator
is used to pump a metered amount of Protex ® anti-
spatter compound to the conductor tube assembly. The
application cycle can be applied anytime there are a few
spare seconds in the weld cycle, during part changes, or
during a cleaning cycle.
The compound is injected into the purge line of the robotic
torch and cable assemblies and coats the nozzle, gas
diffuser, and tip on the conductor tube. In addition to
applying the anti-spatter compound, the compressed air
used with the applicators is used to dislodge any loose
particles.
The QRM-100 Anti-Spatter Mist Applicator has a 24-
volt DC solenoid, which is controlled either by the robot
controller or some other type of power source.
2.04 Standard Features
Frequency adjustments from up to 200 pulses per
minute.
Metering device that sets the amount of anti-spatter
applied with every pulse of the pump.
Air Flow Control.
Output air hose.
1-pint reservoir (Optional: 1-quart size).
Mounting hardware.
QRM-100 Anti-Spatter Applicator
The QRM-100 Anti-Spatter Mist Applicator comes standard
with the items shown in Figure 1. Before starting the installa-
tion, please read and understand the installation and operation
procedures outlined in this manual.
•
•
•
•
•
•
2.01 How to Use this Manual
To ensure safe operation, read the entire manual, including
the chapters on safety instructions and warnings.
Throughout this manual, the words WARNING, CAUTION,
and NOTE may appear. Pay particular attention to the
information provided under these headings. These special
annotations are easily recognized as follows:
WARNING
A WARNING giveS infoRMAtion RegARding
poSSible peRSonAl inJuRy.
CAUTION
A CAUTION refers to possible equipment
damage.
NOTE
A NOTE offers helpful information concerning
certain operating procedures.
2.02 Receipt of Equipment
When you receive the equipment, check it against the
invoice to make sure it is complete and inspect the
equipment for possible damage due to shipping. If there is
any damage, notify the carrier immediately to file a claim.
Furnish complete information concerning damage claims
or shipping errors to the location in your area listed in the
inside back cover of this manual. Include a full description
of the parts in error.
If you want additional or replacement copies of this CD,
please contact Tweco ® Robotics at the address and phone
number in your area listed on the inside back cover of this
manual. Include the Manual number (from page i) and
CD part number: 64-2601.
!
!
SECTION 2:
INTRODUCTION AND DESCRIPTION
