TRANSARC 130i
Manual 0-5283 4-11 BASIC WELDING GUIDE
Electrode Selection Chart
CIGWELD Electrode Selection Chart
Description Diameter Pack Part No. Application
Satincraft 13
2.5mm
2.5mm
3.2mm
3.2mm 1kg
2.5kg
1kg
2.5kg
322135
612182
322136
612183
General purpose electrode suitable for all positional
welding and galvanised steel.
Ferrocraft
12XP
2.0mm
2.0mm
2.5mm
2.5mm
3.2mm
3.2mm 1kg
2.5kg
1kg
2.5kg
1kg
2.5kg
322128
612231
322129
612232
322138
612233
General purpose, extra performance electrode
recommended for all positional (inc. Vertical down)
welding of mild and galvanised steel.
WeldSkill GP
2.0mm
2.0mm
2.5mm
2.5mm
2.5mm
3.2mm
3.2mm
3.2mm 1 kg
2.5 kg
1 kg
2.5 kg
5 kg
1 kg
2.5 kg
5 kg
WEG1020
WEG2520
WEG1025
WEG2525
WEG5025
WEG1032
WEG2532
WEG5032
User-friendly GP electrode for welding thin section mild
and galvanised steels. Excellent for vertical down fillet
welding applications.
Ferrocraft 16
Twincoat
2.5mm
3.2mm 5 kg
5 kg 611752
611753 Hydrogen Controlled type offering exceptional AC/DC
performance in all welding positions.
Satincrome
308L-17
2.5mm
3.2mm 2.5 kg
2.5 kg 611602
611603
Stainless Steel type for 19Cr/10Ni stainless grades
including 201, 202, 301, 302, 303, 304, 304L, 305,
308, etc
Satincrome
309Mo-17
2.5mm
3.2mm 2.5 kg
2.5 kg 611692
611693
Stainless Steel type for 309 and 309L grades. It is also
suitable for welding of dissimilar welding of other 300
series stainless steels.
Satincrome
316L-17
2.0mm
2.5mm
3.2mm
2.5/3.2mm
2,5 kg
2.5 kg
2.5 kg
Blisterpack
611661
611662
611663
322215
Stainless Steel type for welding of matching Mo bearing
grades, 316 and 316L.
Weldall
2.5mm
3.2mm
2.5/3.2mm
2.5 kg
2.5 kg
Blisterpack
611702
611703
322216
High alloy stainless steel type for welding of unknown
steels, repair of die or tool steels and for joining
dissimilar steels. (Not recommended for cast iron).
Castcraft 55 3.2mm 2.5 kg 6117234
For repair and maintenance welding of S.G. cast iron,
meehanite and other cast irons. It produces high
strength weld than Castcraft 100.
Castcraft
100
2.5mm
3.2mm
Blisterpack
2.5 kg
2.5 kg
Blisterpack
611732
611733
322217
Soft, Ductile Nickel type electrode for repair and
maintenance welding of a wide range of cast irons. It
has better “wetting” action than Castcraft 55.
Table 4-1: Cigweld Electrode Selection Chart
Further information on CIGWELD electrodes can be found at the website www.cigweld.com.au.
