186 AC/DC Front Panel Overview
Slide 3
Digital Meters-
Displays both the pre-set and
actual output current and
voltage of the power source.
Also used to display parameters
in programming mode.
AC/DC
Mode,
Pulse and
Purge
Buttons
Process
Selection
Button -
Three modes
are available,
GTAW (LIFT
TIG), GTAW (HF
TIG) & SMAW
(Stick) modes.
Trigger
Control
Button
Multi Function
Control Knob
Programming Parameter
Indicator Lights
