FABRICATOR 252i INSTALLATION/SETUP
INSTALLATION/SETUP 3-4 Manual 0-5155
3.06 Power Source Controls, Indicators and Features
1 2
3
4
5
6 7 8 9
Art # A-10503_AB
Figure 3-1: Fabricator Control Panel
+ -
11
12
13 14
15
Art # A-10504
10
Figure 3-2: Fabricator Front Connections
WARNING
DO NOT TOUCH the electrode wire while it is being fed through the system. The electrode wire will be at
welding voltage potential.
1. Power Indicator
The green power indicator will be illuminated when the welder is turned ON and indicates the presence of power.
