Ultra-cut 200 xt – Tweco 200 XT Ultra-Cut Plasma Cutting System User Manual
Page 44
ULTRA-CUT 200 XT
3-20
INSTALLATION
Manual 0-5273
3. Insert the fiber-optic cable connector into the receptacle on the vertically-mounted circuit board as shown.
Cable must snap into place.
Circuit Board
Fiber Optic Cable
Art # A-04773
4. Tighten the through-hole protector for the fiber-optic cable using hand tools.
5. Reinstall the Cover Panel making sure the ground wire is attached.
