Manual 0-2251 21 INSTALLATION PROCEDURES
3.3 PLASMA AND SECONDARY CONNECTIONS (continued)
Secondary Water
Connections
1. The water source must be capable of delivering a
minimum water pressure of 50 psi (3.5 BAR) and flow
of 8 gph (30.3 lph).
2. Connect the secondary water supply hose to the rear
panel fitting marked SEC. WATER.
The water source does not need to be deionized, but in
water systems with extremely high mineral content a
water softener is recommended. NOTE
Plasma Gas
A-00874
Secondary Gas
Secondary Water
High Flow
Water Shield
Remote Interface
Connection
Figure 3-C Rear Panel Connections
