Manual 0-2251 2-3 INTRODUCTION & DESCRIPTION
2.3 TORCH SPECIFICATIONS
• PCH-150 90° Hand Torch
• PCH-150 70° Hand Torch
• PCM-150 Machine Torch
Standard lengths of 25 ft (7.6 m) or 50 ft (15.2 m).
Extendable in increments of 25 ft or 50 ft up to a maximum
of 150 ft (45.7 m) with available leads extension packages
(see Section 2.4, Options and Accessories)
150 Amps Maximum, Direct Current Straight Polarity
Hand and Machine Torch rated at 100% Duty Cycle
Most materials up to 2.0 in (50.8 mm)
Torch Configurations
Torch Leads Lengths
Cutting Range
Current Rating
Plasma
Secon-
dary
Gases
• Compressed Air
• Oxygen (O
2
)
• Argon/Hydrogen
(Ar/H 2 )
• Nitrogen (N
2
)
• Compressed Air
• Nitrogen (N
2 )
• Carbon Dioxide
(CO
2
)
• Water
Hot Flow *
For Cutting:
22-28 scfh
(10.4-13.2 lpm)
For Gouging:
22-43 scfh
(10.4-20.3 lpm)
For Cutting or
Gouging:
220 scfh
(103 lpm)
8 gph
(30.3 lph)
Pressure
50 psi
(3.4 bar)
50 psi
(3.4 bar)
Min.50 psi
(3.4 bar)
Gas Requirements
* Hot flow is measured with the main arc activated. When
pressure is set correctly the plasma gas flow rate is
significantly higher until the arc is initiated.
PCH-150 90° Hand Torch (without Leads) - 1.0 lb (.45 kg) Weight
NOTE
