ual 0-2554
A-5
APPENDIX
NOTES
1. Recommended plasma pressure setting for 60 ft (18.3 m) total hose length (extension plus leads). For every 10 ft (3 m) of additional
hose length add 2.5 psi (0.17 bar) to the plasma pressure setting.
2. Recommended secondary pressure setting for 60 ft (18.3 m) total hose length (extension plus leads). For every 10 ft (3 m) of addi-
tional hose length add 1.0 psi (0.07 bar) to the secondary pressure setting.
3. Piercing materials 3/4 inch (19.1 mm) and over may shorten torch consumable parts life.
Metric Measurements
Argon-Hydrogen Plasma Cutting Data Chart
Maximizer 300 Torch
Aluminum
Argon/Hydrogen (H-35) Plasma / Nitrogen Secondary
Electrode
Gas
Distributor
Tip End Cap Amperage
Output
Volts
Speed Standoff
Plasma
Pressure
Secondary
Pressure
Pierce
Delay
Pierce
Height
Cat. No. Cat. No. Cat. No. Cat. No. amps vdc m / min mm bar bar seconds mm
20-1025 20-0008 20-1032 20-1004 150 165 1.14 4.78 4.83 1.38 0.25 6.35
20-1025 20-0008 20-1032 20-1004 150 165 0.89 4.78 4.83 1.38 0.37 6.35
20-1025 20-0008 20-1032 20-1004 150 170 0.76 4.78 4.83 1.38 0.50 12.70
20-1025 20-0008 20-1032 20-1004 150 170 0.64 4.78 4.83 1.38 0.50 12.70
20-1025 20-0008 20-1032 20-1004 150 175 0.51 4.78 4.83 1.38 NR NR
19.1
25.4
31.8
Material
Thickness
mm
12.7
15.9
