Manual 0-4686 2-1 Introduction
SECTION 2:
INTRODUCTION
2.01 Overview
Plasma is a gas which has been heated to an extremely
high temperature and ionized so that it becomes elec-
trically conductive. The plasma arc cutting process uses
this plasma to transfer an electrical arc to the workpiece.
The metal to be cut is melted by the heat of the arc and
then blown away.
2.02 General Specifications
Model Description C-100A
Maximum Output 100 Amps
Input Voltage & Phase
230V, 1/3 phase
400V, 3 phase
460V, 1/3 phase
Frequency 50/60Hz
Input Power 230V 1/3 Phase
87/45 Amps
(20/18 kVA)
Input Power 400V 3 Phase
31 Amps
(21.5 kVa)
Input Power 460V 1/3 Phase
48/25 Amps
(22/20 kVa)
Input Fuse 230V ±10% 1Phase
Input Fuse 230V ±10% 3Phase 50 Amp Slow Blow
30 Amp Slow Blow
Input Fuse 400V ±10% 32 Amp Slow Blow
Input Fuse 460V ±10% 1Phase
Input Fuse 460V ±10% 3Phase 30 Amp Slow Blow
30 Amp Slow Blow
No Load Voltage 240V
Load Voltage 120V
Output Current 30 - 100 Amp
Post Flow Time 10 Seconds
Operating Air Pressure
72 psi (.5MPa)
(5 bar)
Maximum Input Air Pressure
125 psi (.86MPa)
(8.6 bar)
Air Flow
400 scfh, 6.6 scfm
(188.7 lpm)
System Duty Cycle Rating* at
Ambient Air Temperatures of
40° C / 104° F.
35% @ 100Amp
System Duty Cycle Rating* at
Ambient Air Temperatures of
40° C / 104° F.
60% @ 85Amp
System Duty Cycle Rating* at
Ambient Air Temperatures of
40° C / 104° F.
100% @ 70Amp
Genuine Cutting Capacity 1 1/4" (30mm)
Maximum Cutting Capacity 1 1/2" (40mm)
Dimension (W x D x H)
12.5" x 27.5" x 20.5"
(318mm x 699mm x
520mm)
Net Weight 122 lbs. (85 kg)
