CUTMASTER 52
PARTS LIST
Manual 0-4961
6-4
6.07 Replacement Parts - for Machine Torches with Unshielded Leads
Item No. Qty
Description
Catalog No.
1
1
Torch Head Assembly without leads (includes items 2, 3, and 14)
9-8220
2 1 Large
O-Ring
8-3487
3 1 Small
O-Ring
8-3486
4
1
PIP Switch Kit
9-7036
5
Unshielded Automated Leads Assemblies with ATC connectors
1
5 - foot / 1.5 m Leads Assembly with ATC connector
4-7850
1
10 - foot / 3.05 m Leads Assembly with ATC connector
4-7851
1
25 - foot / 7.6 m Leads Assembly with ATC connector
4-7852
1
50 - foot / 15.2 m Leads Assembly with ATC connector
4-7853
6
Unshielded Mechanized Leads Assemblies with ATC connectors
1
5 - foot / 1.5 m Le-ads Assembly with ATC connector
4-7842
1
10 - foot / 3.05 m Leads Assembly with ATC connector
4-7843
1
25 - foot / 7.6 m Leads Assembly with ATC connector
4-7844
1
50 - foot / 15.2 m Leads Assembly with ATC connector
4-7845
7
1
11” / 279 mm Rack
9-7041
8
1
11” / 279 mm Mounting Tube
9-7043
9
1
End Cap Assembly
9-7044
10
2
Body, Mounting, Pinch Block
9-4513
11
1
Pin, Mounting, Pinch Block
9-4521
12
1
Torch Holder Sleeve
7-2896
13
1
PIP Plunger and Return Spring Kit
9-7045
1
Pinion Assembly (Not shown)
7-2827
1
5” / 126 mm Positioning Tube (Not shown)
9-7042
