Tweco Auto-Cut 100 Torch Operation - Manual (Page 13)

Torch Data 8-13 Manual 0-4733 Rev. AD
Aluminum
100A
H35 Plasma / N2 Shield
Plasma
(H35)
Shield
(N2)
(ga) (in) inch psi psi Volts
(in)
±0.005
(ipm) (in) (sec) (in)
3/8 0.375 120 50 150 0.188 60 0.350 0.1 0.100
1/2 0.500 120 50 156 0.188 40 0.350 0.4 0.110
5/8 0.625 120 50 160 0.188 30 0.350 0.5 0.113
3/4 0.750 120 50 171 0.250 20 0.350 0.6 0.130
Plasma
(H35)
Shield
(N2)
bar bar Volts
(mm)
±0.1
(mm/min) (mm) (sec) (mm)
8.3 3.4 151 4.8 1450 8.9 0.1 2.6
8.3 3.4 155 4.8 1130 8.9 0.3 2.7
8.3 3.4 159 4.8 830 8.9 0.5 2.8
8.3 3.4 174 6.8 430 8.9 0.6 3.4
100A Aluminum (H35/N2)
Material
Thickness
Cut Flow Pressures
Arc
Voltage
Torch
Working
Height
Travel
Speed
Initial
Piercing
Height
Pierce
Delay
Kerf Width
@ Rec.
Speed
Material
Thickness
Cut Flow Pressures
Arc
Voltage
Torch
Working
Height
20
(mm)
10
12
15
Travel
Speed
Initial
Piercing
Height
Pierce
Delay
Kerf Width
@ Rec.
Speed
Tip
35-1062
Electrode
35-1080
Plasma
Gas Distributor
35-1041
Art # A-04938
Cartridge
35-1020
Shield Cup
35-1016 Shield Cap
35-1034
Shield
Gas Distributor
35-1272
