PAGE 4 MAGNUM 620E PUMP OPERATION / MAINTENANCE MANUAL
Figure 1-1 Pump Dimensions (Standard & Optional Quick Change Base)
ATTENTION: The pump should be operated with clean, dry air or nitrogen.
Particulate, water and oils in the air supply can damage the pump.
NOTE:
1. It is recommended that a filter be placed on the discharge side of the pump.
2. Although extensive efforts are made to deliver pumps to our customers
completely dry, new pumps may contain residual moisture from their final DI
water test.
Recommended Maximum Operating Levels:
Temperature Range Supply Pressure Max
< 60°C 80 PSI (5.5 bar)
60°C - 110°C** 60 PSI (4.1 bar)
*110

C Maximum Fluid Temperature
