PAGE 18 MAGNUM 620E PUMP OPERATION / MAINTENANCE MANUAL
4.2 RECOMMENDED SPARE PARTS
KR620E-00-A Spares Rebuild Kit, which includes:
Part No Qty Description
KD620-00-A 1 Diaphragm Kit
Includes: (2) AW004 Diaphragm
98001415 4 Check Ball
98002334 4 O-ring, PTFE
98003322 2 Shaft Seal
AM064 1 Shaft
AM083 2 Check Cap Seal
AW017 1 Damper Port Seal
In critical applications a spare pump is recommended to minimize possible down
time during service intervals.
4.3 TOOLS
The following tool kit is recommended as standard service equipment.
KT620-00-A Tool Kit, which includes:
Part No Qty Description
98003108 1 Torque Wrench, 30- 150 ft/lb., 1/2” Drive
98003150 1 Tool Case
98003305 1
1/4” Drive Handle
98003306 1 Adjustable End Wrench
T000B0014 1 Check Sleeve Removal Tool
T0137 1 Rebuild Fixture
T0129 1 Strap Wrench
T0144 1 Head Removal Wedge
T0146 1 3/
4” Pin Tool
T0148 1 1/2” Pin Tool
T0149 1 Optic Cap Pin Tool
T0154 1 Check Sleeve Insertion Tool
T0155 1 Maxim 25 Bullet Shaft
T1044 1 Cleaning Tool
Additional tools required not supplied with tool kit
0-48 IN. – OZ, Dial Indicating Torque Screwdriver
3 IN. LBS Torque Limiting Screwdriver (preset 48 in-oz)
