MAGNUM 620E PUMP OPERATION / MAINTENANCE MANUAL PAGE 3
1 INSTALLATION
1.1 UNPACKING
After unpacking, the pump should be checked for any damage that may have
occurred during shipment. Damage should be reported to the carrier
immediately.
The following items should be included within the shipping container:
Qty Item Description
1 620E Magnum 620E Pump
1 M620E Operation/Maintenance Manual
Optional Accessories:
1 or 2 DP-C-6 End-of-Stroke Probe
(1) Required for Cycle (2) Required for EOS
2 DP-L-32 Leak Probe
1.2 UTILITIES / HOOK-UP
It is recommended that the pump be positioned within 15° from level to maintain
self-priming ability and pumping efficiency. Allow sufficient room for tubing
connectors. The pump mounting is shown in Fig. 1-1 below.
Air connections are typically made using 3/8” OD x 1/4” ID tubing up to 12 ft. If
more distance is required it is recommended to increase tubing size to ½” tube
for the air lines to minimize losses.
Air Inlet: 3/8 ” FNPT (3/8” Dia. [8mm] supply tube minimum).
Air Supply: 20-80 psig (1.4 – 5.5 bar) clean dry air or nitrogen (see
Performance Charts, Section Error! Reference source not
found.).
Fluid Ports: 1” NPSM – additional adaptor port options available.
Inlet/Outlet adaptor fittings and Surge Suppressor require
torqueing during pump installation. See Section 2 for hook-up
diagram and torque values.
