PAGE 20 MAGNUM 620E PUMP OPERATION / MAINTENANCE MANUAL
4.5 PARTS LIST
ILL
NO PART NO QTY DESCRIPTION MATERIAL
1 AW073* 2 EOS PLUG PTFE
2 AW065 2 Dress Ring, Trebor PP
3 98002243 2 Plug, 3/8 NPT PE
4 AW070 2 Head, 620E, Molded, Multi Port, Diff GFPP
AW070-01* 2
Head, 620E, EOS , Molded, Multi Port,
Diff
GFPP
5 AW004 2 Diaphragm PTFE
6 98003722 2 Locking SCR Push Plate PTFE
7 AW071 2 Push Plate PTFE
8 AW072 1 Shaft PTFE
9 98003322 2 Ring, PTFE, Backup PTFE
10 AW001 1 Body PTFE
11 AM060 2 Suction Sleeve PTFE
12 98002334 4 O-ring, PTFE, -312 PTFE
13 98001415 4 Check Ball, PTFE, ¾” PTFE
14 AM061 2 Discharge Sleeve PTFE
15 AM083 2 Check Cap Seal PTFE
16 AW003 2 Check Bore Cap PTFE
17 AW014 1 Damper Port Cap PTFE
18 AW017 1 Damper Port Seal PTFE
19 AW062 1 Base, Non Quick Release GFPP
20 98003207 4 Screw, GFPP, Black, ¼-20 PP
21 AM023** 1 Base Locking Lever PP
22 C0102** 1 Base, Quick Release PP
23 AW057** 1 Base. Pump Mount PP
24 98003071** 1 Screw, PP, 10-32 PP
25 98003768* 2 EOS seal Viton
* EOS (End-of-Stroke) Option only. ** Quick Change Base option only (A6)
4.6 DECONTAMINATION CLEAN-UP
To help remove potentially dangerous chemicals prior to service or shipment, the
pump should be flushed with DI water or disassembled and thoroughly cleaned.
Allow DI water to flush through the inlet and out the outlet to prevent pressure
build up.
CAUTION: When handling pump wear appropriate personal protection
gear, including safety glasses.
