# Parameter Name Description Options
12
14
Input Linking Selects whether Input 1 and Input 2 gains are con-
trolled independantly (Unlinked), together (1-2), or
together with MS decoding (1-2MS).
» Unlinked
• 1-2
• 1-2MS
13
15
Output Source - XLR The audio channels sent to the analog XLR outputs.
Left of the comma represents left output and right of
the comma represents right output.
» 1,2
• 3,4
• 5,6
• 7,8
• 1357,2468
• 12345678
14
16
Output XLR 1 Attenuation Attenuate analog output 1 by 1 dB increments. » 0 dB
(numeric 0-20)
15
17
Output XLR 2 Attenuation Attenuate analog output 2 by 1 dB increments » 0 dB
(numeric 0-20)
16
18
Input Delay to Output Toggles whether or not Input Delay affects audio
signal to the main audio outputs.
» On
• Off
17
19
Headphone Source The audio channels sent to the headphone output.
Left of the comma represents left headphone channel
and right of the comma represents right headphone
channel.
» 1,2
• 3,4
• 5,6
• 7,8
• 1357,2468
• 12345678
18
20
Headphone: LCD A/V Align Delays audio to Headphone output to align with video
on LCD.
» Off
• On
Timecode/Sync
# Parameter Name Description Options
1 Timecode Mode Sets the running mode for the internal timecode
generator and/or the method which the PIX recorder
receives SMPTE timecode. ( See “Timecode
Modes”, page 41 )
» Off
•
Freerun
• Freerun Auto Mute
• Record run
• 24h Run
• 24h Run Auto Mute
• Ext TC (LTC)
• Ext TC (LTC Halt)
» Ext TC (SDI, HDMI)
• Ext TC (HDMI) PIX 220i only
2 Drop Frame Enable Enable or disable drop frame timecode. » Off
• On
