Sound Devices PIX 220i - Manual (Page 61)

Audio
# Parameter Name Description Options
1 Audio Input Physical source to derive recorded audio from. » Analog XLR
• AES (Digital) XLR 1-2ch
• AES (Digital) XLR 1-4ch
• SDI/HDMI 2ch
• SDI 4ch
• SDI 6ch
• SDI 8ch
• Analog 2ch + SDI/HDMI 2ch
• Analog 2ch + SDI 4ch
• Analog 2ch + SDI 6ch
• OFF
2 Analog 1 Source Selects the input level and whether or not phantom
power should be applied to analog input 1.
» Mic
• Mic 48V
• Line
• Line 48V
3 Analog 2 Source Selects the input level and whether or not phantom
power should be applied to analog input 2.
» Mic
• Mic 48V
• Line
• Line 48V
4 Analog 1 Low cut Engages low-cut filter on analog Input 1 at the speci-
fied frequency.
» OFF
• 40Hz
• 80Hz
• 120Hz
• 160Hz
• 200Hz
• 240iHz
5 Analog 2 Low cut Engages low-cut filter on analog Input 2 at the speci-
fied frequency.
» OFF
• 40Hz
• 80Hz
• 120Hz
• 160Hz
• 200Hz
• 240iHz
6 Low cut Slope Selects the curve of the analog low-cut filters. • 6dB/oct
» 12dB/oct
7 input Limiter (1,2) Toggles input limiters on analog inputs. » On
• Off
8 Analog 1 Polarity Selects normal or inverse polarity for analog Input 1. » Normal
• Reverse
9 Analog 2 Polarity Selects normal or inverse polarity for analog Input 2. » Normal
• Reverse
10 Input 1 Delay Applies the specified amount (in milliseconds) of
digital delay to Input 1.
» 0ms
(numeric 0-500)
11 Input 2 Delay Applies the specified amount (in milliseconds) of
digital delay to Input 2.
» 0ms
(numeric 0-500)
12 Input 3 Delay Applies the specified amount (in milliseconds) of
digital delay to Input 3.
» 0ms
(numeric 0-500)
13 Input 4 Delay Applies the specified amount (in milliseconds) of
digital delay to Input 4.
» 0ms
(numeric 0-500)
Se
tup Menu Op
tions
PIX 220i and PIX 240i Video Recorder User Guide
59
