W217602518
Before beginning the installation, please read the following instructions and the drivers warning notice thoroughly. The
included warning decal must be placed in the passenger compartment in clear view of all occupants.
NOTE: If any items are missing from this kit or you need assistance with installation, call 1-800-888-0650
for technical assistance. DO NOT return to your dealer.
Start with the vehicle parked on a hard (concrete or asphalt) level surface. Using a measuring tape, measure from the lip
of the wheel rim to the lip of the fender directly above the wheel . Record the measurements below for reference later in
the installation.
Driver’s (Left) rear:_________ Passenger’s (Right) rear:_________
NOTE: Before disassembling your vehicle, compare the parts in the box(s) with those listed in the parts list(s).
21-8395 10-10 NAD-37788
REQUIRED TOOLS:
FLOOR JACK
JACK STANDS
VICE GRIPS
MEASURING TAPE
AIR LINE TUBING CUTTER #2 PHILLIPS SCREW DRIVER
7/32" ALLEN WRENCH
RATCHET
5/16" WRENCH & SOCKET
3/8" WRENCH & SOCKET 1/2" WRENCH & SOCKET
9/16" WRENCH & SOCKET
8MM WRENCH & SOCKET
10MM WRENCH & SOCKET
13MM WRENCH & SOCKET
PART LIST
QTY PART # DESCRIPTION QTY PART # DESCRIPTION
1 21-3582-9378 FULL AIR MANIFOLD (2 CORNER)
1 21-3582-9379 WIRE HARNESS W/KNEEL SWITCH
1 21-3582-9380 FULL AIR ECU
1 21-3582-9008 TUBING 1/4 RED 30 FT
4 21-3582-3414 BAIL CLAMP 3/8-16, 9.5 X 4.25 X 2.5
2 A26-760-9047 140/95MM TUNABLE 369MM
PLASTIC CAP
2 21-3582-5691 DODGE 1500 TOP PLATE
2 21-3582-5690 DODGE 1500 UPPER MOUNT
4 21-3582-5705 AIR ACCESSORY SYSTEM
FRAME BRACKET
1 21-3582-5713 AIR ACCESSORY SYSTEM MOUNT
PLATE
1 21-3582-9127 AIR TANK 3 GALLON
1 24-3582-9285 AIR COMPRESSOR 280C
1 WR1-760-9009 HOSE CUTTER
2 21-3582-5698 DODGE 1500 HEIGHT SENSOR
BRACKET
1 21-3582-5707 HEIGHT SENSOR LINKAGE BRACKET
1 21-3582-9401 SEALED PRESSURE SWITCH 120/90
4 21-3582-3416 3/8 - 16 X 2.0 THREADED STUD
16 21-3582-3067 3/8-16 FLANGE MAC LOCK NUT
4 21-3582-3022 3/8-16 FLANGE LOCK NUT
1 24-3582-3311 M8 X 1.25 X 15MM HHCS
1 24-3582-3314 M8 FLAT WASHER
4 24-3582-3087 10-32 X 1” MACHINE SCREW
8 24-3582-3086 3/16 FLAT WASHER
4 21-3582-3088 10-32 UNF NYLON LOCK NUT
2 21-3582-3424 1/4-20 X 3/4 BUTTON HEAD BOLT
2 21-3582-3055 04 X 02 MALE CONNECTOR
3 21-3582-3128 1/8 NPT SWIVEL ELBOW 1/4 TUBE
1 21-3582-3031 1/4 PTC ELBOW FITTING
1 21-3582-3269 1/4 NPT PLUG
2 21-3582-3032 INFLATION VALVE PTC
1 21-3582-3066 COMPRESSOR TEE FITTING
3 21-3582-3025 1/4 PUSH TO CONNECT TEE
