Ultima Voice2
Owner’s Manual
26
VOICE2 DIMENSIONS & WEIGHT
On-Cradle Height: 14.7 inches (373 mm)
On-Cradle Width: 25.5 inches (648 mm)
On-Stand Depth: 14.0 inches (356 mm)
Shipping Weight: 74.5 Pounds. (33.8 kg)
Using optional pedestal:
On-Pedestal Height: 24.2 inches (614 mm)
On-Pedestal Width: 28.0 inches (711 mm)
On-Pedestal Depth: 16.8 inches (427 mm)
Low-Frequency Extension -10 dB at 36 Hz
-6 dB at 49 Hz
-3 dB at 60 Hz Indicates the low-frequency response of the loudspeaker. Studies have shown
that the –10dB specification best correlates to controlled listening tests. At low
frequencies, most loudspeaker and listening room combinations demonstrate
significant room gain, which produces an increase in levels as frequencies
decrease. Unlike the –3 dB specification, the –10dB specification reflects the
steepness of low-frequency roll-offs.
SPECIFICATIONS
Specifications Value Definition
Note
Specifications are subject to change without notice.
25.5 inches (647mm)
14.2 inches (361mm)
15.8 inches, (401mm)
15.63 inches (397mm)
14.07 inches (357mm)
15.64 inches (39
7mm)
14.70 inches(373mm)
