7 LFO Programming Software
User Guide
Frequency-Response
Display Window
Connection Status
Indicator
Menu
Tabs
Adjustment Tabs (shown
with System Tab active)
Crossover Controls
Subwoofer Standalone/
Daisy-Chain Selector
Auto Sense Control Delay Units Adjustment
Frequency-Response
Curve Display Tabs
Frequency-Response
Plot Control Adjustments
Mute Buttons
Fixed EQ Control
Subwoofer System controls: When the "System" adjustment tab is active the following controls are available for the connected subwoofer:
NOTE: The Subwoofer System controls only affect the subwoofer that is actively connected to the computer via USB at the time the adjustments
are made. In systems with multiple subwoofers you will need to connect each subwoofer to the computer one at a time and set these controls
individually for each subwoofer.
• Delay units adjustment: This control lets you set the units for the subwoofer delay adjustment to inches, centimeters or milliseconds (ms). See page
9 for details.
• Subwoofer standalone/daisy-chain selector: In systems that have more than one Revel subwoofer, use this control to designate each subwoofer
in the chain according to where it is connected within the chain. Always designate the subwoofer that is directly connected to your system's preamp/
processor/AVR as "1"; designate the next subwoofer in the chain as "2," and so on.
• Auto Sense control: This control lets you determine how long the subwoofer will remain turned on after the audio signal ceases when the subwoofer's
Power Mode switch is set in the "Auto" position.
• Crossover controls: These controls determine the settings of the subwoofer's internal crossover network.
IMPORTANT: If you have connected the subwoofer to a processor/AVR that has internal bass management (low-pass crossover) for the subwoofer/
LFE output, you should set both crossover controls to "Flat Response."
