LFO Programming Software
User Guide
7. I n the LFO interface window, select the Import Curve tab. The Import Curve dialog box will appear.
8. Make sure that the Curve Type is set to "Measured Results" and the Channel is set to "Subwoofer", then use the Browse function to select the curve
you just saved into your computer from AudioTools.
9. Select OK.
10. The LFO interface window will return, with the Frequency Response Display window showing both the Target Response curve and your system's
subwoofer Measured Response curve.
Target
Curve
Measured
Curve
• If additional curves are displayed (usually as fl at lines at 0dB level), select "Measured Response Curves" and "Target Response Curves" and make
sure that only the Subwoofer curve is set to be visible in each (see illustration below).
Visible
Position
Adjustment
Not Visible
