12 LFO Programming Software
User Guide
6. Select Acoustics, then select FFT (Fast Fourier Transform). The measurement graph screen will appear.
Wrench
Button
Decay Time
Button
Resolution
Button
Start/
Pause
Button
Stop
Button
7. Tap the Wrench button. The FFT Setup window will appear. Make sure all the settings match those shown below, then tap Done:
8. Tap the Resolution button. In the slide-in window that appears, set the resolution to 1/24th-octave then tap the button again.
9. Tap the Decay Time button. In the slide-in window that appears, momentarily set the decay time to Fast and then leave it set to Average.
