Icon Series LTS 1.0
8 Technical Data
ICON IC 112 LA
Connections 1x XLR Line In, 1x XLR Line Through, 1x XLR Sub Out,
2x BVNet RJ45 IN/OUT, 1x Ethernet RJ45 Internal System Guard
Input impedance 20 kOhm
Input sensitivity +16 dBu, +4 dBu, 0 dBu, -10 dBu, variable
Max. Input level +22 dBu
Frequency response +/- 3 dB 134 Hz – 17 kHz (LTS System Filter)
Frequency response +/- 10 dB 108 Hz – 17 kHz
Sensitivity 1W@1m¹ 109 dB (120 Hz – 16 kHz)
Max SPL calculated¹ 139 dB, based on peak power handling capacity
Max SPL peak¹ 136 dB SPL @ 10% THD
Max SPL¹ 131 dB SPL @ 10% THD, 120 Hz – 12 kHz
134 dB SPL @ 10% THD, 120 Hz – 5 kHz
Amplifier Mid 1x 1000 W / Class D @ 4 Ohm
Amplifier Hi 1x 600 W / Class D @ 4 Ohm
Limiters RMS Limiter, Peak Limiter, Subsonic Filter
MF Speaker 12" Neodym
HF Speaker 1,4"
Directivity 60° x 40° CD horn
Crossover Frequency 900 Hz, 24 dB/ Oct.
Rigging points Aeroquip
Handles 4, integrated
Grille Metal Grille with black acoustic foam
Castors Dolly with four 100 mm castors
Accessories ICON Tilt-Unit, 5°, 10°, 15°, dust cover
Dimensions (BxHxT) 50 x 60 x 81 cm / 19-11/16 x 23-5/8 x 31-7/8"
Weight 49,9 kg/ 110 lbs. (without dolly)
ICON IC 118 BA
Connections 1x XLR Input, 1x XLR Through,
2x Ethernet RJ45 Internal System Guard
Input impedance 20 kOhm
Input Sensitivity +4 dBu
Max. Input Level +22 dBu
Frequency response +/- 3 dB 41 Hz- fx
Frequency response – 10 dB 33 Hz - fx
Sensitivity 1W@1m¹ 105 dB
Max SPL calculated¹ 138 dB, based on peak power handling capacity
Max SPL peak¹ 138 dB SPL @ 10% THD, 90 Hz - 100 Hz
Max SPL¹ 136 dB SPL @ 10% THD
Amplifier Sub 1x 2000 W / Class D @ 4 Ohm
Limiters Subsonic Filter, System Controller with Peak Limiter
Woofer 18" Neodym
Pole mount Two M20 threaded base plates
Handles 8, integrated
Grille Metal Grille with black acoustic foam
Castors Dolly with four 100 mm castors
Accessories dust cover
Dimensions (WxHxD) 50 x 90 x 81 cm / 20-1/2 x 28-1/2 x 28-1/8"
Weight 54,1 / 119,2 lbs (without dolly)
1) Measurements taken under half-space conditions
General Technical Data
Max. Power Consumption 1050 W (IC 112 LA), 1880 W (IC 118 BA)
Max. Current Consumption 4,5 A (IC 112 LA), 8,1 A (IC 118 BA)
Internal fuse 4 AT / 10 AT (IC 112 LA), 10 AT (IC 118 BA)
Mains voltage range 220 V - 240 V
Mains connector Neutrik Powercon
This is to certify that
ICON IC 112 LA
ICON IC 118 BA
complies with the provisions of the Directive of
the Council of the European Communities on
the approximation of the laws of the Member
States relating to electromagnetic compatibility
according to EMC directive 2004/108/EC and
low voltage directive 2006/95/EC.
This declaration of conformity of the European
Communities is the result of an examination
carried out by the Quality Assurance Depart-
ment of STAMER GmbH in accordance with Eu-
ropean Standards EN61000-6-1, EN61000-6-2,
and EN 60065 for low voltage.
Magdeburger Str. 8, 66606 St. Wendel, Germany
Lothar Stamer Dipl.Ing.
Managing Director
St. Wendel, den 06/29/2009
