GOSSEN Foto- und Lichtmeßtechnik 8
– Transfer that EV value from the display to
the setting window in the calculator rings
and place it precisely under the red indi-
cator line.
– All the suitable combinations of aperture
(f-stops) - t (shutter speeds) can now be
seen at the upper part of the circular
scales (see previous example).
2.3 Flash measurement
2.3.1 Setting the sync speed
(measuring time)
– Press the function button for selecting the
function „flash measurement“. A small
stroke in front of the sync time will appear
in the display to signal „flash metering“.
– Keep the function button pressed down
until the ok signal sounds. The display will
now show the sync speed blinking.
– Use the measuring key to input the desi-
red sync speed, in the range of 1 sec to
1/500 sec. and confirm by pressing the
function button.
2.3.2 Measuring
– Push the measuring key.
The Digiflash is ready to measure for
30 sec, as long as „F“ in the display is on.
