7 E-flite Ascent PNP Assembly Manual
Wing Assembly
Required Parts
Fuselage Wing panel (right and left)
Aluminum wing tube #4 washer (2)
4-40 x 1/2-inch socket head screw (2)
Required Tools and Adhesives
Ball driver: 3/32-inch
 1. Locate the aluminum wing tube and slide it into the
hole in the wing root of one of the wing panels. The tube
will slide in roughly half of its length.
 2. Slide the remaining wing panel onto the tube. The two
wing panels will fit tightly together.
 3. Slide the dowels at the leading edge into the holes in
the fuselage as shown.
