16 E-flite Ascent PNP Assembly Manual
 2. Plug the elevator servo, rudder servo and speed
control leads into the appropriate ports of the receiver.
On a model that uses rudder and elevator control, it is
common to plug the rudder servo into the aileron port.
 3. Use the supplied hook and loop tape to attach the
receiver inside the fuselage.
 4. Install the motor battery inside the fuselage. Place
the hook and loop tape on the battery and battery tray
to keep the battery from moving forward or backward
in the fuselage. The battery installation is completed by
securing the battery with the hook and loop strap that is
pre-installed in the fuselage.
 5. Turn on the radio and check the operation of the
servos. Center the rudder stick and trim. After centering
the rudder, use a #1 Phillips screwdriver to tighten
the screw that secures the rudder pushrod wire. Once
complete with the rudder, check the elevator centering as
well.
