21 E-flite Extra 260 480 ARF Assembly Manual
Stabilizer and Elevator
Required Parts
Fuselage w/wing installed
Stabilizer Elevator
CA hinge (4)
Required Tools and Adhesives
Hobby knife Felt-tipped pen
Ruler T-pins
Thin CA
 1. Position the stabilizer into the slot in the aft end
of the fuselage. Check that the stabilizer is centered
in the fuselage.
 2. Measure from the stab tip to the wing tip. Adjust the
stab until the measurements are equal.
A A
A=A
 3. View the airframe from the rear and make sure the
wing and stab are parallel. If not, lightly sand the stab
saddle until they are.
